Códigos de avería Ssangyong (motor)
Completion requirements
|
|
DESCRIPCIÓN DE LA AVERÍA |
|
P0102 |
Low HFM Sensor Signal (Circuit Open) |
|
P0100 |
Air Mass Flow (HFM) Malfunction |
|
P0103 |
High HFM Sensor Signal (Circuit Short) |
|
P0105 |
Supply Voltage Fault to Booster Pressure Sensor |
|
P0106 |
High Booster Pressure Sensor Signal |
|
P0107 |
Booster Pressure Sensor Open/GND Short |
|
P0108 |
Booster Pressure Sensor Short |
|
P0109 |
Low Booster Pressure Sensor Signal |
|
P0110 |
Intake Air Temperature Circuit Malfunction - Source Power Problem |
|
P0112 |
Intake Air Temperature Circuit Malfunction - Open |
|
P0113 |
Intake Air Temperature Circuit Malfunction - Short |
|
P0115 |
Supply Voltage Fault to Coolant Temperature Sensor |
|
P0117 |
Coolant Temperature Sensor Malfunction - Open |
|
P0118 |
Coolant Temperature Sensor Malfunction - Short |
|
P0120 |
Accelerator Pedal Sensor #1 Malfunction - Supply Voltage Fault |
|
P0122 |
Accelerator Pedal Sensor #1 Malfunction - Open |
|
P0123 |
Accelerator Pedal Sensor #1 Malfunction - Short |
|
P0180 |
Fuel temperature sensor - Malfunction |
|
P0182 |
Fuel temperature sensor - Short to Ground |
|
P0183 |
Fuel temperature sensor - Short to B+ |
|
P0190 |
Supply Voltage Fault to Fuel Rail Pressure Sensor |
|
P0191 |
Fuel Rail Pressure Sensor Signal Fault |
|
P0192 |
Fuel Rail Pressure Sensor Malfunction - Open |
|
P0193 |
Fuel Rail Pressure Sensor Malfunction - Short |
|
P0201 |
Injector #1 Circuit Open |
|
P0202 |
Injector #2 Circuit Open |
|
P0203 |
Injector #3 Circuit Open |
|
P0204 |
Injector #4 Circuit Open |
|
P0205 |
Injector #5 Circuit Open |
|
P0215 |
Main Relay Fault - Stuck |
|
P0219 |
Too Small Clearance of Crank Angle Sensor |
|
P0220 |
Accelerator Pedal Sensor #2 Malfunction - Supply Voltage Fault |
|
P0222 |
Accelerator Pedal Sensor #2 Malfunction - Open |
|
P0223 |
Accelerator Pedal Sensor #2 Malfunction - Short |
|
P0245 |
Turbo Charger Actuator Circuit Fault - Short |
|
P0246 |
Turbo Charger Actuator Circuit Fault - Short to B+ |
|
P0251 |
IMV Driver Circuit Malfunction - Short |
|
P0253 |
IMV Driver Circuit Malfunction - Short to Ground |
|
P0255 |
IMV Driver Circuit Malfunction - Open |
|
P0263 |
Injector #1 Balancing Fault |
|
P0266 |
Injector #2 Balancing Fault |
|
P0269 |
Injector #3 Balancing Fault |
|
P0272 |
Injector #4 Balancing Fault |
|
P0275 |
Injector #5 Balancing Fault |
|
P0325 |
Accelerometer #1 (Knock Sensor) Malfunction |
|
P0330 |
Accelerometer #2 (Knock Sensor) Malfunction |
|
P0335 |
No Crank Signals |
|
P0336 |
Too Large Clearance of Crank Angle Sensor |
|
P0341 |
Cam Position Sensor Malfunction (Poor Synchronization) |
|
P0344 |
Cam Position Sensor Malfunction |
|
P0372 |
Crank Angle Sensor Malfunction |
|
P0400 |
EGR Control Valve Fault |
|
P0560 |
Battery Voltage Malfunction |
|
P0562 |
Low Battery Voltage |
|
P0563 |
High Battery Voltage |
|
P0571 |
Brake Pedal Switch Fault |
|
P0606 |
ECU Watchdog Fault |
|
P0633 |
Immobilizer Fault (refer to immobilizer section) |
|
P0641 |
ECU Supply Voltage 1 Fault (5 V) |
|
P0642 |
ECU Supply Voltage 1 Fault - Low (5 V) |
|
P0643 |
ECU Supply Voltage 1 Fault - High (5 V) |
|
P0651 |
ECU Supply Voltage 2 Fault (5 V) |
|
P0652 |
ECU Supply Voltage 2 Fault - Low (5 V) |
|
P0653 |
ECU Supply Voltage 2 Fault - High (5 V) |
|
P0671 |
#1 Glow Plug Fault - Open |
|
P0672 |
#2 Glow Plug Fault - Open |
|
P0673 |
#3 Glow Plug Fault - Open |
|
P0674 |
#4 Glow Plug Fault - Open |
|
P0675 |
#5 Glow Plug Fault - Open |
|
P0685 |
Main Relay Malfunction |
|
P0697 |
ECU Supply Voltage Fault (2.5 V) |
|
P0698 |
ECU Supply Voltage Fault - Low (2.5 V) |
|
P0699 |
ECU Supply Voltage Fault - High (2.5 V) |
|
P0700 |
TCU Signal Fault |
|
P0704 |
Clutch switch malfunction |
|
P1105 |
Barometric Sensor Circuit Short |
|
P1106 |
Booster Pressure Sensor Malfunction |
|
P1107 |
Barometric Sensor Circuit Short/GND Short |
|
P1108 |
Barometric Sensor Circuit Short |
|
P1109 |
Booster Pressure Sensor Initial Check Fault |
|
P1115 |
Coolant Temperature Sensor Malfunction |
|
P1120 |
Accelerator Pedal Sensor #1 Malfunction |
|
P1121 |
Accelerator Pedal Sensor #2 Malfunction |
|
P1122 |
Accelerator Pedal Sensor Malfunction (Limp Home Mode) |
|
P1123 |
Accelerator Pedal Sensor Malfunction (Torque Mode) |
|
P1124 |
Accelerator Pedal Sensor Malfunction - Stuck |
|
P1148 |
Accelerometer (Knock Sensor) Learning Fault |
|
P1149 |
Too High Water Level in Fuel Filter |
|
P1170 |
Torque Trim Fault - High |
|
P1171 |
#1 Injector MDP Malfunction |
|
P1172 |
#2 Injector MDP Malfunction |
|
P1173 |
#3 Injector MDP Malfunction |
|
P1174 |
#4 Injector MDP Malfunction |
|
P1175 |
#5 Injector MDP Malfunction |
|
P1190 |
Fuel Rail Pressure Sensor Initial Signal Fault |
|
P1191 |
Pressure Build Up - Too Slow |
|
P1192 |
Fuel Rail Pressure Sensor Initial Signal Fault - Low |
|
P1193 |
Fuel Rail Pressure Sensor Initial Signal Fault - High |
|
P1201 |
Injector #1 Circuit Short |
|
P1202 |
Injector #2 Circuit Short |
|
P1203 |
Injector #3 Circuit Short |
|
P1204 |
Injector #4 Circuit Short |
|
P1205 |
Injector #5 Circuit Short |
|
P1235 |
VGT Operation Fault |
|
P1252 |
Too High IMV Pressure |
|
P1253 |
Minimum Rail Pressure Control Malfunction (IMV Fault) |
|
P1254 |
Maximum Rail Pressure Control Malfunction (IMV Fault) |
|
P1256 |
Too Small Transfer Pressure Fuel in Rail Pressure System |
|
P1257 |
Too Large Transfer Pressure Fuel in Rail Pressure System |
|
P1258 |
Too Small High Pressure Fuel in Rail Pressure System |
|
P1259 |
Too Large High Pressure Fuel in Rail Pressure System |
|
P1286 |
Low Resistance for Injector #1 wiring harness |
|
P1287 |
High Resistance for Injector #1 wiring harness |
|
P1288 |
Low Resistance for Injector #2 wiring harness |
|
P1289 |
High Resistance for Injector #2 wiring harness |
|
P1290 |
Low Resistance for Injector #3 wiring harness |
|
P1291 |
High Resistance for Injector #3 wiring harness |
|
P1292 |
Low Resistance for Injector #4 wiring harness |
|
P1293 |
High Resistance for Injector #4 wiring harness |
|
P1294 |
Low Resistance for Injector #5 wiring harness |
|
P1295 |
High Resistance for Injector #5 wiring harness |
|
P1405 |
EGR Solenoid Valve Short Malfunction - Short |
|
P1406 |
EGR Solenoid Valve Malfunction - Short |
|
P1480 |
Condenser Fan #1 Circuit Malfunction - Open |
|
P1481 |
Condenser Fan #1 Circuit Malfunction - Short |
|
P1482 |
Condenser Fan #1 Circuit Malfunction - Short to Ground |
|
P1500 |
Vehicle Speed Fault |
|
P1526 |
Condenser Fan #2 Circuit Malfunction - Open |
|
P1527 |
Condenser Fan #2 Circuit Malfunction - Short |
|
P1528 |
Condenser Fan #2 Circuit Malfunction - Short to Ground |
|
P1530 |
#1 Heater operating circuit - Open |
|
P1531 |
#1 Heater operating circuit - Short |
|
P1532 |
#1 Heater operating circuit - Short to Ground |
|
P1534 |
#2 Heater operating circuit - Open |
|
P1535 |
#2 Heater operating circuit - Short |
|
P1536 |
#2 Heater operating circuit - Short to Ground DI10-48 |
|
P1540 |
Air Conditioner Operating Circuit Fault - Open |
|
P1541 |
Air Conditioner Operating Circuit Fault - Short |
|
P1542 |
Air Conditioner Operating Circuit Fault - Short to Ground |
|
P1571 |
Brake Lamp Signal Fault |
|
P1572 |
Brake Lamp Signal Fault |
|
P1600 |
ECU Shut Down Fault |
|
P1601 |
ECU Fault |
|
P1602 |
ECU Fault |
|
P1603 |
ECU Fault |
|
P1604 |
ECU Fault |
|
P1605 |
ECU Fault |
|
P1606 |
ECU Fault |
|
P1607 |
ECU Injector Cut Fault |
|
P1608 |
ECU Fault |
|
P1611 |
Injector Bank #1 Malfunction - Low Voltage |
|
P1612 |
Injector Bank #1 Malfunction - High Voltage |
|
P1614 |
ECU C2I/MDP Fault |
|
P1615 |
ECU Fault |
|
P1616 |
ECU Fault |
|
P1618 |
Injector Bank #2 Malfunction - Low Voltage |
|
P1619 |
Injector Bank #2 Malfunction - High Voltage |
|
P1620 |
ECU Fault |
|
P1621 |
ECU Fault |
|
P1622 |
ECU Fault |
|
P1630 |
Wrong response from Immobilizer (refer to immobilizer section) |
|
P1631 |
Immobilizer Fault (refer to immobilizer section) |
|
P1632 |
Immobilizer Fault (refer to immobilizer section) |
|
P1633 |
Immobilizer Fault (refer to immobilizer section) |
|
P1634 |
Immobilizer Fault (refer to immobilizer section) |
|
P1635 |
No response from Immobilizer (refer to immobilizer section) |
|
P1636 |
Immobilizer Fault (refer to immobilizer section) |
|
P1671 |
#1 Glow Plug Fault - Short (+B) |
|
P1672 |
#2 Glow Plug Fault - Short (B+) |
|
P1673 |
#3 Glow Plug Fault - Short (B+) |
|
P1674 |
#4 Glow Plug Fault - Short (B+) |
|
P1675 |
#5 Glow Plug Fault - Short (B+) |
|
P1676 |
Glow Plug Communication Fault |
|
P1677 |
Glow Plug Controller Fault |
|
P1678 |
Glow Plug Malfunction - Open |
|
P1679 |
Glow Plug Malfunction - Short |
|
P1680 |
Glow Plug Malfunction - Short to Ground |
